Product Details
| TYPE C | |||||||||||
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
||
| No. | DN | inch | mm | mm | Wall Thickness mm |
Wall Diff Max mm |
Mpa | Mpa | mm | kg/m | kg/㎡/year |
| C8.0 | 8.0 | 5/16" | 8.0±0.4 | 15.2±0.5 | 3.6 | 0.4 | 3.5 | 23 | 55 | 0.146 | 1.6 |
| C11.5 | 11.4 | 13/32" | 11.4±0.4 | 18.4±0.5 | 3.5 | 0.4 | 3.5 | 22 | 70 | 0.196 | 1.6 |
| C13 | 13.0 | 1/2" | 13.2±0.4 | 21.0±0.5 | 4.0 | 0.4 | 3.5 | 20 | 75 | 0.231 | 1.6 |
| C15.2 | 15.2 | 5/8" | 15.2±0.4 | 23.0±0.5 | 3.9 | 0.4 | 3.5 | 21 | 85 | 0.257 | 1.6 |
| CH8.0 | 8.2 | 5/16" | 8.0±0.4 | 19.0±0.5 | 5.4 | 0.4 | 3.5 | 21 | 70 | 0.285 | 1.6 |
| CH10.5 | 10.5 | 13/32" | 10.5±0.4 | 23.0±0.5 | 6.3 | 0.4 | 3.5 | 21 | 85 | 0.393 | 1.6 |
| CH13a | 13.0 | 1/2" | 13.0±0.4 | 25.4±0.5 | 6.2 | 0.4 | 3.5 | 22 | 85 | 0.332 | 1.6 |
| CH13b | 13.0 | 1/2" | 13.0±0.4 | 23.0±0.5 | 5.0 | 0.4 | 3.5 | 22 | 95 | 0.441 | 1.6 |
| CH16 | 16.1 | 5/8" | 16.1±0.4 | 28.6±0.5 | 6.3 | 0.4 | 3.5 | 18 | 105 | 0.470 | 1.6 |
| C19 | 19.0 | 3/4" | 19.0±0.4 | 28.5±0.6 | 4.8 | 0.4 | 3.5 | 18 | 105 | 0.428 | 1.6 |
|
TYPE E |
|||||||||||
|
|
|
|
|
|
|
|
|
|
||
| No. | DN | inch | mm | mm | Wall Thickness mm |
Wall Diff Max mm |
Mpa | Mpa | mm | kg/m | kg/㎡/year |
| C8.0 | 8.0 | 5/16" | 8.0±0.4 | 15.2±0.5 | 3.6 | 0.4 | 3.5 | 23 | 55 | 0.146 | 1.6 |
| C11.5 | 11.4 | 13/32" | 11.4±0.4 | 18.4±0.5 | 3.5 | 0.4 | 3.5 | 22 | 70 | 0.196 | 1.6 |
| C13 | 13.0 | 1/2" | 13.2±0.4 | 21.0±0.5 | 4.0 | 0.4 | 3.5 | 20 | 75 | 0.231 | 1.6 |
| C15.2 | 15.2 | 5/8" | 15.2±0.4 | 23.0±0.5 | 3.9 | 0.4 | 3.5 | 21 | 85 | 0.257 | 1.6 |
| CH8.0 | 8.2 | 5/16" | 8.0±0.4 | 19.0±0.5 | 5.4 | 0.4 | 3.5 | 21 | 70 | 0.285 | 1.6 |
| CH10.5 | 10.5 | 13/32" | 10.5±0.4 | 23.0±0.5 | 6.3 | 0.4 | 3.5 | 21 | 85 | 0.393 | 1.6 |
| CH13a | 13.0 | 1/2" | 13.0±0.4 | 25.4±0.5 | 6.2 | 0.4 | 3.5 | 22 | 85 | 0.332 | 1.6 |
| CH13b | 13.0 | 1/2" | 13.0±0.4 | 23.0±0.5 | 5.0 | 0.4 | 3.5 | 22 | 95 | 0.441 | 1.6 |
| CH16 | 16.1 | 5/8" | 16.1±0.4 | 28.6±0.5 | 6.3 | 0.4 | 3.5 | 18 | 105 | 0.470 | 1.6 |
| C19 | 19.0 | 3/4" | 19.0±0.4 | 28.5±0.6 | 4.8 | 0.4 | 3.5 | 18 | 105 | 0.428 | 1.6 |
Application: Used in the A/C system of the vehicle and the other cooling system
Inner Tube: TYPE C（(EPDM/IIM）TYPE E（SCM/EPDM）
Barrier: PA
Middle Layer: EPDM/CSM
Reinforcement: PET/PVA braid
Cover: EPDM Smooth/Cloth Wrapped
Temperature Range: -40℃ to +135℃（-40℉ to +275℉）
Application standard: SAE J2064 QC & T664-2005
Applicable refrigerant: R134a
